3.4 Flats on shafts
Fig. 10: Flats on shafts
Some shafts have flat surfaces at those points where the components are
screwed on. This stabilizes the connection and makes adjustment easier.
Always ensure that the screw faces are completely flush with the surface.
(1) - Shaft (2) - Surface
①
②
