Setting the feed dog
Service Instructions 967 - 02.0 - 12/2015
43
Setting steps
1. Set the upper stitch length adjusting wheel to the maximum stitch length.
2
. Loosen the setscrews (1).
3. Put the handwheel into the 190° position.
4. Press stitch adjustment lever (3) downwards and observe the feed dog
and needle in the process.
5. Turn the pusher eccentric (2) such that the feed dog and needle no
longer move when the stitch adjustment lever (3) is pressed.
6. Tighten the setscrews (1).
8.2.2 Setting the feed dog height at top dead center
The feed dog reaches the maximum stroke height at top dead center when
t
he position of the handwheel is 190°.
Proper setting
Place the feed dog in the uppermost positio
n by turning the handwheel.
Th
e upper edge of the feed dog protrudes 1.3 mm above the throat
plate.
Cover
• Tilt the machine head ( p. 10).
WARNING
Risk of injury!
Crushing injuries from moving parts.
Switch off the machine before checking and setting
th
e feed dog height.
