Setting the feed dog
Service Instructions 967 - 02.0 - 12/2015
39
8 Setting the feed dog
The position and the movement of the feed dog and needle bar have to be
coordinated such that the needle pierces exactly in the center of the nee-
dle hole of the feed dog.
Sequence
First check the following setting:
• Needle bar linkage ( p. 47)
8.1 Setting the feed dog position
Proper setting
When the stitch length is set to 0 and the needle is at the bottom dead center:
 Th
e center of the feed dog opening (2) lines up with the axle of the
needle.
Cover
• Tilt the machine head ( p. 10).
WARNING
Risk of injury!
Crushing injuries from moving parts.
Switch off the machine before setting the feed dog
p
osition.
