Adjusting the sewing foot feed
64
Service Instructions 967 - 02.0 - 12/2015
Setting steps
1. Screw in the setscrew (4) so that a stroke is available.
2
. Position the upper stitch length adjusting wheel to 0.
3. Loosen the setscrews (2).
4. Turn the stroke eccentric (1) such that the feeding foot touches down
on the feed dog when the handwheel is in the 95° position and the tip
of the needle is at the height of the upper edge of the feeding foot.
When doing so, do not move the stroke eccentric (1) laterally on the
axle.
5. Tighten the setscrews (2).
6
. Loosen the setscrew (4) far enough so that the plates (3) are, once
again, in a line.
