Working basis
14 Service Manual 867 Version 02.0 - 04/2015
Removing the head cover
1. Loosen the screws (1).
2. Remove the head cover (2).
Fitting the head cover
1. Fit the head cover (2).
2. Tighten the screws (1).
3.3.4 Removing and fitting the valve cover
Fig. 4: Removing and fitting the valve cover
Removing the valve cover
1. Undo all four screws (1).
2. Remove the valve cover (2).
Important: When removing the valve cover, be sure not to pull off any
cables.
Fitting the valve cover
1. Fit the valve cover (2).
2. Tighten all four screws (1).
Important: When fitting the valve cover, be sure not to pull off any
cables.
(1) - Screws (2) - Valve cover
②
①
