6.5.7.3 Battery Gauge Minimum/Maximum
Parameter Possible Values Default HHP Lite Std Adv
Battery Gauge Minimum 16 - 24 V 22 V
✓
Battery Gauge Maximum 19 - 27 V 24.4 V
✓
Battery Gauge Minimum sets the voltage at which the battery gauge indicates an empty
battery.
Battery Gauge Maximum sets the voltage at which the battery gauge indicates a full
battery.
6.5.7.4 Battery Gauge Warning
Parameter Possible Values Default HHP Lite Std Adv
Battery Gauge High Warning 24 - 32 V 29 V
✓ ✓
Battery Gauge Low Warning 18 - 26 V 23.4 V
✓ ✓
Battery Gauge High Warning sets the voltage at which a high-voltage condition is indicated.
Battery Gauge Low Warning sets the voltage at which a low-voltage condition is indicated.
6.5.7.5 Battery Cut-Off Voltage
Parameter Possible Values Default HHP Lite Std Adv
Battery Cut-Off Voltage 16 - 24 V 21 V
✓ ✓ ✓
This parameter is only used when Deep Discharge Beeper has the value 'Yes'.
The Battery Cut-Off Voltage specifies the voltage at which the battery is empty and battery
damage will occur if the battery is discharged any further. If the battery voltage falls below
this value, the RHINO2 gives the user an audible warning. The cut-off level for lead-acid
batteries is 21 V.
Note
An audible and visible deep discharge warning is required to comply with ISO7176-14.
6.5.7.6 Battery Gauge Dead-band
Parameter Possible Values Default HHP Lite Std Adv
Battery Gauge Dead-band 0 - 6 V 3.5 V
✓
Prevents the battery gauge from increasing when the battery voltage recovers after driving.
If the scooter is driving, the battery voltage will be lower than when the scooter stands still.
However, the actual charge of the battery does not increase during standstill, even though
the voltage has increased. This can cause the battery gauge to increase as well, showing a
charge that is too high during standstill.
Battery Gauge Dead-band makes sure that the battery gauge only shows a higher charge
when the battery is actually being charged. Any increase in battery voltage that is lower
than the value of Battery Gauge Dead-band is ignored.
GBK51948 RHINO2
Installation Manual Issue 5
Programming - Page 109
