Eaton EASY-E4 Series User Manual

4. Operation
4.6 Transfer program to the easyE4 device
easySoft 7 Project View\Project\Card...
Figure 65: Card setup dialog box
You can use the Card section to specify the storage location, i.e., the drive, where the
microSD memory card is located.
In addition, this section will show the available information about the memory card.
Click on the PC => Card button to select the transfer option you want.
The File selection dialog box will appear.
116
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
