Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Year time switch YT01 should switch on on March 1st, at 00:00, and remain switched
on until November 1st, at 00:00.
The YT year time switch must be assigned the following parameters:
Programming view/YT01/Year time switch (new) parameters tab
Figure 126: Figure: Entry screen in the programming software
Example 3: Select “public holidays"
Year time switch YT01 should switch on on 12/05 of every year at 00:00 and remain
switched on until 12/28 of every year at 00:00.
The YT year time switch must be assigned the following parameters:
Programming view/YT01/Year time switch (new) parameters tab
Figure 127: Figure: Entry screen in the programming software
Example 4: Select time range
Year time switch YT01 should switch on on 05/01 of every year at 00:00 and remain
switched on until 11/02 of every year at 00:00.
The YT year time switch must be assigned the following parameters:
Programming view/YT01/Year time switch (new) parameters tab
Figure 128: Figure: Entry screen in the programming software
easyE4 11/18 MN050009 EN www.eaton.com
213

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
