Eaton EASY-E4 Series

Appendix
A.1 Dimension and weight specifications
Width x Height x Depth
(without plug)
71.5 mm x 90 mm x 58 mm (2.81" x 3.54" x 2.28")
Weight 0.20 kg
Expansion devices with 4 space unit front dimension
EASY-E4-UC-16RE1,EASY-E4-DC-16TE1
Figure 258: Dimensions in mm (Inch)
Width x Height x Depth
(without plug)
71.5 mm x 90 mm x 58 mm (2.81" x 3.54" x 2.28")
Weight 0.20 kg
