Eaton EASY-E4 Series User Manual

Appendix
A.1 Dimension and weight specifications
Expansion devices with 2 space unit front dimension
EASY-E4-UC-8RE1,EASY-E4-DC-8TE1, EASY-E4-DC-6AE1
Figure 259: Dimensions in mm (Inch)
Width x Height x Depth
(without plug)
3.5 mm x 90 mm x 58 mm (1.4" x 3.54" x 2.28")
Weight 0.18 kg
582
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
