3. Commissioning
3.6 Automatic booting of the memory card
Transfer program
Click the PC-> Card button.
The File selection dialog box will appear.
If the list does not show any files, this means that there are no programs on the
card.
Enter the target name of the program in the selection box, e.g. <test>. The name
can be different from the designation of *.e80 in easySoft 8. Or you select a
name from the list.
Confirm your selection with OK. This will transfer the program for the device
selected in the Project view to the card.
If the project is a NET application, the "Selection of NET station" dialog box will
appear.
Select the NET station with the program that you want to transfer to the
microSD memory card, e.g., <NET station NT1>.
A plausibility check will then be run – please refer to → "Plausibility check", page 608.
If this plausibility check is completed successfully, the following prompt will appear.
easyE402/24 MN050009ENEaton.com
131
