4. Operation
4.6 Transfer program to the easyE4 device
AUTO-IP ✓
DHCP
Static IP
Tab. 73: System Option-
s\Ethernet\Address mode
Select the network setting you want.
Email Test?
YES
NO
Tab. 74: System option-
s\Ethernet\Email test
Possibility to check the e-mail function.
→ Section "Setting up the e-mail function",
page 740
Set up a new Ethernet connection on your PC's operating system.
To do this, go to Windows Network and Sharing Center and set up a LAN connection
over Internet Protocol Version 4 (TCP/IPv4). Then enter an IP address in the same
range you used for the device, but with a different device number.
Example using Windows
Fig. 94: Ethernet connection on PC
You can now connect to your easySoft 8 device with the easyE4 programming soft-
ware.
See also
 → Section "Establishing an Ethernet connection and transferring a program or
visualization project", page 117
186
easyE402/24 MN050009ENEaton.com
