6. Function blocks
6.1 Manufacturer function blocks
Retention
The function block does not recognize retentive data.
Example of a analog value comparator function block when using the EDP pro-
gramming language
I01----A01Q1-----------------Ä Q01
I02----A01CY-----------------S Q02
Example of an AR configuration on a device display
When using the function block in the circuit diagram for the first time, use OK to auto-
matically enter the display of function blocks on the device display, as shown in the
following figure.
A02 GT +
>I1
>F1
>I2
>F2
>OS
>HY
Fig. 178: Parameters on the display
Enter the function block settings here. The display contains the following elements:
 
A02
Function block: Analog comparator, number 02
GT
Operating mode: Greater than
+
Parameter set can be called via the PARAMETERS menu
>I1
Comparison value 1, is compared with the comparison value 2 at
>I2, Value range: -2147483648… 2147483647
>F1
Gain factor for >I1 (>I1 = >F1. Value)
Value range: -2147483648… 2147483647
>I2
Comparison value 2 I1, Value range: -2147483648… 2147483647
>F2
Gain factor for >I2 (>I2 = >F2. Value) Value range: -2147483648 …
2147483647
>OS
Offset (zero point offset) for the value of >I1 Value range: -
2147483648… 2147483647
>HY
Positive and negative switching hysteresis for comparison value I2,
Value range: -2147483648… 2147483647
See also
 → Section "AR - Arithmetic", page 335
 → Section "AV - Average", page 340
 → Section "CP – Comparator", page 349
 → Section "LS - Value scaling", page 353
 → Section "MM - Min-/Max function", page 358
 → Section "PW - Pulse width modulation", page 367
 → Section "PM - Performance map ", page 361
334
easyE402/24 MN050009ENEaton.com
