Eaton easyE4

6. Function blocks
6.1 Manufacturer function blocks
PDPDPD
PW
MEME
0
1
Fig. 188: PW pulse at the function block output when SV =1400, ME = 93 ms, PD=1000 ms
PW
PDPDPD
MEME
0
1
Fig. 189: PW pulse at the function block output when SV = 3218, ME = 93 ms, PD=1000 ms
PW
PDPDPD
ME
ME
0
1
Fig. 190: A constant signal is signaled at the function block output when SV = 3768, ME = 93 ms, PD=1000
ms; E1 = 1
PD: Pulse duration
PW: Pulse width
ME: Minimum on duration, Minimum off duration
See also
 → Section "AR - Arithmetic", page 335
 → Section "AV - Average", page 340
 → Section "CP – Comparator", page 349
 → Section "LS - Value scaling", page 353
 → Section "MM - Min-/Max function", page 358
 → Section "PM - Performance map ", page 361
