Eaton easyE4 User Manual

6. Function blocks
6.1 Manufacturer function blocks
The function block and its parameters
Function block inputs

Description Note
(bit)
EN
1: Activates the function block.

(DWord)
I1
Input value
Value range: -32768…+32767
TG
Recovery time TG [0.1 s]
Value range: 0…65535
The value 10 corresponds to a recovery
time of 1000 ms.
KP
Proportional gain Kp [%]
Value range: 0 ... 65535
Value range: 0…65535
The value 100 corresponds to a KP
(factor) of 1.
The value 50 corresponds to a KP of 0.5.
Assigning operands
You can assign the following operands to the function block inputs that are numeric
inputs.
Operands Value inputs
Constant, timer constant
1)
x
MD, MW, MB - Markers
x
NB, NW, ND - NET markers
2)
x
nNB, nND, nND- NET markers
2)
NET station n
x
IA - Analog input
x
QA - Analog output
x
QV - QV - Numeric output of a FB
x
1)
Only on function blocks T, AC
2)
Only on projects with ≥ 2 base devices on NET
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1
x
M - Markers
x
RN - Input bit via NET
2)
x
SN - Output bit via NET (send)
2)
x
N - Net marker bit
2)
x
nN - NET marker bit
2)
NET station n
x
ID: Diagnostic alarm
x
LE - Output backlight
x
P device buttons
x
I - Bit input
x
Q - Bit output
x
Q - Bit output of a FB
x
2)
Only on projects with ≥ 2 base devices on NET
easyE402/24 MN050009ENEaton.com
383
