Eaton easyE4

6. Function blocks
6.1 Manufacturer function blocks
Enter the function block settings here. The display contains the following elements:
SR01 shift register
Function block: SR shift register, number 01
DW
Operating mode: Double word
+
Parameter set can be called via the PARAMETERS menu
>I1
Input value DW forwards:
Integer value range:
-2,147,483,648 to +2,147,483,647
>I2
Input value DW backwards:
Integer value range:
-2,147,483,648 to +2,147,483,647
D1>
Register value 1 of the shift register,
Integer value range:
-2,147,483,648 to +2,147,483,647
for all registers
D2>
Register value 2
D3>
Register value 3
D4>
Register value 4
D5>
Register value 5
D6>
Register value 6
D7>
Register value 7
D8>
Register value 8
See also
 → Section "Organizing marker ranges", page 234
 → Section "Retention function", page 636
 → Section "BC - Block comparison", page 410
 → Section "BT - Block transfer", page 418
 → Section "MX - Data multiplexer", page 429
 → Section "TB - Table function", page 447
 → Section "RE - Recipe records ", page 433
