6. Function blocks
6.1 Manufacturer function blocks
Description Note
0 or 1 depending on the function
block.
No edge evaluation of T bit
input
When this checkbox is enabled, the
data will be transmitted to the NET
based on cycle times. It will be
transmitted every nth cycle, where
n can be defined in the parameters
for the function block.
If the checkbox is disabled, manual
transmission triggering with an
edge at function block input T_ will
be required.
Write data to NET after each …
<n> cycle
Can only be selected if No edge
evaluation of T bit input is enabled.
Parameter display
+ Call enabled
Constants can be edited on the
device, as can function block para-
meters when using the EDP pro-
gramming language.
Simulation not possible
Other
Retention
The function block does not recognize retentive data.
See also
→ Section "Setting up a NET group", page 706
→ Section "GT - Get values from NET", page 452
→ Section "SC - Synchronizing clock via NET", page 461
