6. Function blocks
6.1 Manufacturer function blocks
6.1.7.4 D - Text display editor
easySoft 8 features a text display editor that can be used to design text displays. In
order to be able to access it, there must first be a text display function block in the
Programming view work pane and the you must have clicked on the function block.
Open the Text display parameters tab and click on the Text display editor button. The
text display editor will be opened in a separate window.
Properties Text display editor
Text displays are put together with a text display editor that makes input with free
text and actual values from various function blocks possible.
This editor features the following properties:
l
6 lines x 16 characters - 96 elements
l
Texts can be positioned freely within the text display
l
Analog value, timer value, and time value processing
l
Message texts, times, dates, and checkboxes as input and output elements
l
Simple value entry and controls
l
User-controlled acknowledgements
l
Ticker text with variable speeds
l
Variable display times
l
Prioritization by the user
l
Multi-language capabilities
484
easyE402/24 MN050009ENEaton.com
