6. Function blocks
6.1 Manufacturer function blocks
Timing relay value display
Time functions can be implemented using the timing relay value display elements.
You can conveniently display the reference value or the running time value in its own
display element. Please note that the number of characters, and the size of the dis-
play element accordingly, is fixed. To configure the element, you will need to select
the timing relay function block number you want and configure the parameters you
want. You can also reference operands such as markers directly as a source for the
display, in which case you will need to make sure that the data format used in the
operand is the format for a timer value.
