Eaton easyE4 User Manual

6. Function blocks
6.3 UF - User function block
Click on the Program/ Configure user function block... menu option.
Inside the pane, click on the tab with the same name as the user function block,
e.g., <UF – Light timer V1.10>, and then click on the "Configure user function
block" button in the toolbar.
Right-click on the tab for the user function block in the work pane and select the
Configure... option.
or
In the work pane, click on the <Main program> tab.
Go to the list of operands and function blocks / User function blocks folder ,
right-click on the function block, and then select the Configure... option.
The Configure user function block dialog box will appear.
Enter all parameters.
Confirm your input and close the dialog box by clicking on OK or pressing the
<Return> key.
The changes will be applied to the user function block. If you want the changes to be
saved beyond runtime, the user function block will need to be saved with the Pro-
gram/Save user function block menu option or with the UFxx/Save context menu
option.
The Name, Version, and Programming method fields have already been described in
the "Creating a user function block" field. Please note that, although the "Configure
user function block" dialog box will show the programming language you originally
selected, it will no longer be possible to change it.
