7. System settings
7.6 Ethernet
7.6 Ethernet
This submenu can be used to configure the addresses for the easyE4 device.
The other station must also be configured accordingly in order for it to be possible to
establish a connection.
The last line on the status display will indicate whether there is an active connection.
New easyE4 base devices will come with the AUTO IP setting configured by default.
In order to configure the settings differently on the EASY-E4-...-12...C1(P), use the
menu structure and go to System Options\Ethernet
The submenu is only provided in English
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 98: Main menu
SECURITY
SYSTEM
MENU LANGUAGE
DELETE PROGR.
NET
ETHERNET
UPDATE
Tab. 99: System options
ADDRESS MODE
IP ADDRESS
SUBNET MASK
GATEWAY ADDRESS
DNS SERVER
easyE RTD
Email Test
Tab. 100: System option-
s\Ethernet
Use the cursor buttons to enter the device's
IP address.
IP-ADDRESS
000.000.000.000
Tab. 101: System Option-
s\Ethernet\IP Address
Select the network setting you want.
AUTO-IP ✓
DHCP
Static IP
Tab. 102: System Option-
s\Ethernet\Address mode
Used to manage remote control permissions for
controlling the easyE4 with the EASY-RTD-....
ACCESS INHIBIT
Tab. 103: System option-
s\Ethernet\easyE RTD
Tab. 97: Ethernet configuration on device
easyE402/24 MN050009ENEaton.com
625
