7. System settings
7.9 Setting the startup behavior
7.9.1 Enabling / disabling the RUN START option
Only possible on base devices with a display.
7.9.1.1 Configuration on a base device with a display
In order to configure it, the program must be stopped.
STOP ✓ RUN
Operating mode changes may be protected with a password.
Go to the main menu.
Go to SYSTEM OPTIONS\SYSTEM.
Select the RUN START menu option.
Press the OK button to enable and disable the option.
Display Status 
RUN START ✓
Active
The program will start as soon as the device is switched on
(the device will switch to RUN mode).
RUN MODE
Disabled
The program will need to be started separately (the device
will remain in STOP mode).
The RUN START option will be enabled by default on the EASY-E4-..., as
well as after a factory reset.
What will happen if the program is deleted
The startup mode setting is a device function and will be retained even if the circuit
diagram is deleted.
Upload/download to memory card or PLC
The setting will be retained when a valid program is transferred.
7.9.2 Enabling / disabling the CARD START option
The mode for starting up with a memory card is intended for applications in which it
is necessary for it to be possible to change programs easily and quickly by changing
the memory card.
If the program on the memory card is different to the program in the easyE4 device,
the program from the card will be loaded on power up first of all and then started in
RUN mode. If the programs only contain different function block SETPOINT values
(constants), the program on the memory card is not loaded.
The program is retained in the device and is started. If there is no circuit diagram on
the memory card the device will remain in STOP mode. For a detailed description of
what this option does, please refer to → "Functions of the microSD memory card",
page 145.
Default setting CARD START inactive
easyE402/24 MN050009ENEaton.com
631
