7. System settings
7.9 Setting the startup behavior
7.9.2.1 Configuration on a base device with a display
In order to be able to configure this option, the program must be in STOP mode. If it is
not, the device will point this out.
Go to the main menu.
Go to SYSTEM OPTIONS\SYSTEM.
Select the CARD START menu option.
Press the OK button to enable and disable the option.
If there is a checkmark ü next to the menu option, the program will be loaded from
the memory card and applied as soon as the easyE4 device is switched on.
If there is no check mark, the current program will be kept.
7.9.2.2 Configuration in easySoft 8
You can enable and disable this option in easySoft 8.
Select the device you want from the catalog in the Project view
Click on the System settings tab.
Go to the Memory card / device ID section and find the checkbox for Card start.
To turn on, enable the checkbox by clicking on it.
To turn off, disable the checkbox by clicking on it.
See also
 → Section "Configuring the microSD card and device ID", page 643
632
easyE402/24 MN050009ENEaton.com
