10. easyE4 communication Connection to other devices
10.14 Using the web client
Menu bar 2 Description  easySoft 8  Webclient  Device
Show/hide catalog

–

x

–
RUN
Button used to select the easyE4 oper-
ating state : green RUN, red STOP

x

x

x
IOX
Displays the status of the easyCon-
nect bus (IO eXtension)
IOX - highlighted in gray: No expan-
sion devices are connected or fault at
the easyConnect bus.
Possible causes:
l
Configuration not OK
l
Expansion device defective
l
Expansion device has no sup-
ply voltage
l
Communication error to an
expansion device
IOX - highlighted in green: easyCon-
nect bus in operation

–

–

–
Start
Show selection in the catalog

–

x

–
Web client cycle time  –  x  –
Show/hide menu bar

–

x

–
10.14.2.2 Catalog
Menu bar 2 Description
Start
Web client start menu with the most important information regarding the connected
device.
Display
The remote display will be shown in the work pane (only the administrator has access to
this remote display). This display is operated exactly the same way as the easyE4 base
device itself.
operands
Operands can be modified. The administrator always has write permissions for local
operands. Users can also be assigned these permissions. However, access to the
marker range through the web client must first be enabled in easySoft 8 and, if neces-
sary, read permissions for I/O must be assigned as well – please refer to → "Enable
marker (write)", page 714 as well.
NET operands
NET operands can be modified. The administrator always has write permissions for his
own NET markers. However, access to the NET marker range through the web client
must first be enabled in easySoft 8 – please refer to → "Enable marker (write)", page
714 as well.
Other users will be able to modify operands if write permissions have been set up for
them in the access control settings – please refer to → "Access control", page 714
Parameter list
The user can compose a list of operands that he would like to observe and/or edit.
Diagnostics
Shows the diagnostic messages that are currently present – please refer to → "Oper-
