10. easyE4 communication Connection to other devices
10.15 Setting up the e-mail function
Please keep in mind that using characters that do not conform to
ASCII code will take more than one byte per character.
l
Sender domain (64 bytes); "easyE4" by default
Enter the hostname or the domain for the easyE4 device itself as the sender
domain. This information will be used to log in to the mail server.
l
Email service port of the SMTP server;
The service port will depend on the selected security option. If an external pro-
vider is used for the email service, the service port must be queried from the rel-
evant provider.
For example, Gmail uses port 587 for the connection security STARTTLS and port
465 for SSL/TLS.
l
Connection security:
l
Not encrypted
l
STARTTLS
l
SSL/TLS (most common connection security protocol)
The DNS name, mail server domains and service port are defined by the
email provider.
Often times, you will be able to find the entire domain name by running a
simple Internet search by <SMTP server> followed by the mail server; for
example Yahoo, Googlemail, gmx.
An email account must definitely be set up with the mail server. If easyE4 should
transfer the email via a public network, an email account must be set up with a pro-
vider. The login data must be entered in the following fields for the email account:
l
Login name (32 Byte)
l
Login password (32 Bytes)
A check mark next to the field Login password shows that you repeated the pass-
word correctly.
System Messages
You can define for which events easyE4 is to send emails in the system messages
area.
NET error occurred
Operating state changed
Program deleted
Configuration error occurred
possible causes can be that one or more SWD participants are missing,
the connection between easyE4 base device and easy communication module is
interrupted because, for example, the plug connector is missing
or the easy communication module is deenergized.
742
easyE402/24 MN050009ENEaton.com
