10. easyE4 communication Connection to other devices
10.16 easy communication modules
2
≧ 2 s
SWD4-...LF-...
1
SWD4-8MF2
Fig. 343: Connecting EASY-COM-SWD-…
1. Connect the SmartWire-DT ribbon cable to the SWD-OUT connector.
2. Switch on the supply voltage.
3. Configure the SmartWire-DT line
