Eaton easyE4 User Manual

10. easyE4 communication Connection to other devices
10.16 easy communication modules
configuration, the SmartWire-DT line will be ready to start transferring data.
l
The target configuration stored in the easyE4 base device will be compared with
the project configuration defined in easySoft 8:
If the target configuration matches the project configuration, the Config LED will
light up with a solid green light.
10.16.1.3 LED status messages on the EASY-COM-SWD-… communication module
LED POW/RUN EASY-COM-SWD-…
Shows the status of the POW supply voltage, as well as the RUN and STOP modes.
Off
Malfunction or no supply voltage
Green, continuous light
Supply voltage OK, RUN mode
Green,
Flashing, 1 Hz
Supply voltage OK, STOP mode
Green,
Flashing, 3 Hz
Supply voltage OK, STOP mode
EASY-COM-SWD-… and easyE4 are unable to exchange data
e.g. bus interface connector not plugged in, faulty or easyE4 switched off
Green,
Flashing, 10 Hz
Device waiting for firmware update
Green,
Flashing, 0.5 Hz
Firmware update in progress
Config LED onEASY-COM-SWD-…
Shows whether the SmartWire-DT coordinator project configuration defined in
easySoft 8 matches the target configuration for the SmartWire-DT line stored on the
easyE4 base device.
Off
l
No project configuration present.
l
Incorrect target configuration (see LED SWD).
Red, continuous light
The project configuration and the stored target configuration are not compatible
with each other.
Green,
Flashing, 2.5 Hz
The project configuration is compatible with the stored target configuration.
Green, continuous light
The project configuration matches the stored target configuration
easyE402/24 MN050009ENEaton.com
761
