Eaton easyE4

Appendix
A.4 Required memory for function blocks
CP - Comparator Connected to

Memory Required
Function block input-
s/outputs
Operand

bytes
EQ
Q2

7
GT
Q3

7
TOTAL
  77

T – Timing relay Connected to

Memory Required
Function block input-
s/outputs
Operand

bytes
T (not connected)
  55
EN
I1

7
RE
I2

7
ST
I3

7
I1
5 ms

11
I2
–

0
Q1
Q1

7
QV
QA1  7
TOTAL
  101
Tab. 148: Memory Required FB T
The D text display function block heavily depends on the configured display and input
elements and their texts. Every display and input element requires memory itself.
Moreover, the texts available for the element also require memory. Identical texts in
several display or input elements hardly require any additional memory due to com-
pression technology.
