Settings
Contextual help of the web interface – 121
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Mapping table content:
Address (hex): register address in hexadecimal
Address (1-base): register address in 1-base format
Type: Register/Discrete
Size in bytes
Number of Modbus registers
Writable: True/False
Representation: Int16/Uint16/String/Boolean/...
Name
Description
Unit
Status to 0: status when the register equal 0
Status to 1:status when the register equal 1
Available: True/False –Shows if the register is available on current Device
Value: Shows current value of the register on current Device
3.7.6.4 Default settings and possible parameters - Modbus
Default setting Possible parameters
Modbus RTU Enabled — Inactive
Baud rate (bps) — 19200
Parity — Even
Stop bits – 1
Enabled — Inactive/Active
Baud rate (bps) —
1200/2400/4800/9600/19200/38400/57600/115200
Parity — None/Even/Odd
Stop bits – 1/2
Modbus TCP Enabled — Inactive
Port — 502
Enabled — Inactive/Active
Port — x-xxx
Mapping configuration No mapping Name – 128 characters maximum
Map – Eaton ModbusMS compatible
Transport – RTU/TCP
Device ID – from 1 to 247
Access – None/Read only/Read/Write
Illegal read behaviour – Return exception/Return
zeros
Coil/register base address shift – No shift/Shift by
1 (JBUS)
File is generated in real time and will take into account the Device capabilities and values at the time of the
generation.
Table in the downloaded file will show all possible registers, only the one showing Available equal to True will be
supported by your system.
This setting is only for the Modbus Network ModuleINDGW
