Edimax CAP1300 - Page 42

AP, Managed AP, Repeater & Client Bridge Modes
42
System
Model
Displays the model number of the access point.
Product Name
Displays the product name for reference, which consists of
“AP” plus the MAC address.
Uptime
Displays the total time since the device was turned on.
System Time
Displays the system time.
Boot From
Displays information for the booted hardware, booted from
internal memory.
Firmware
Version
Displays the firmware version.
MAC Address
Displays the access point’s MAC address.
Management
VLAN ID
Displays the management VLAN ID.
IP Address
Displays the IP address of this device. Click “Refresh” to
update this value.
Default
Gateway
Displays the IP address of the default gateway.
DNS
IP address of DNS (Domain Name Server)
DHCP Server
IP address of DHCP Server.
Wired LAN Port Settings
Wired LAN
Port
Specifies which LAN port (1 or 2).
Status
Displays the status of the specified LAN port (connected or
disconnected).
VLAN Mode/ID
Displays the VLAN mode (tagged or untagged) and VLAN ID
for the specified LAN port. See VI-2-5 VLAN.
Wireless 2.4GHz (5GHz)
Status
Displays the status of the 2.4GHz or 5GHz wireless (enabled
or disabled).
MAC Address
Displays the access point’s MAC address.
Channel
Displays the channel number the specified wireless
frequency is using for broadcast.
Transmit
Power
Displays the wireless radio transmit power level as a
percentage.
