Edimax CAP1300 - Page 43

AP, Managed AP, Repeater & Client Bridge Modes
43
RSSI
Received Signal Strength Indicator (RSSI) is a measurement
of the power present in a received radio signal.
Wireless 2.4GHZ (5GHz) / SSID
SSID
Displays the SSID name(s) for the specified frequency.
Authentication
Method
Displays the authentication method for the specified SSID.
See VI-3 Wireless Settings.
Encryption
Type
Displays the encryption type for the specified SSID. See VI-3
Wireless Settings.
VLAN ID
Displays the VLAN ID for the specified SSID. See VI-2-5 VLAN.
Additional
Authentication
Displays the additional authentication type for the specified
SSID. See VI-3 Wireless Settings.
Wireless Client
Isolation
Displays whether wireless client isolation is in use for the
specified SSID. See VI-2-5 VLAN.
Wireless 2.4GHZ (5GHz) / WDS Status
MAC Address
Displays the peer access point’s MAC address.
Encryption
Type
Displays the encryption type for the specified WDS. See
VI-3-3-4 WDS.
VLAN Mode/ID
Displays the VLAN ID for the specified WDS. See VI-3-3-4
WDS.
Select “Refresh” to refresh all information.
