Appendix A2
A2.4.9 Fit accessory menu
Under the Setup menu. Scroll by pressing UP/DOWN keys. Press ENTER to open a sub menu or CANCEL to exit back
to the Setup menu. A security code is needed to enter the Fit accessory menus: 538.
For an accessory press the UP/DOWN keys to select Fitted or Not Fitted and press ENTER to accept or CANCEL to
exit back to the Commands menu.
Note: Inlet isolation valves additionally have an option of fitted no feedback for use where there are no position
feedback switches fitted to the inlet isolation valve.
Table A20 - Accessory menu
Accessory Parameter
Isol Valve… (Inlet isolation valve)
Water Sensor…
Active gauge…
N2 Flow Sensor… (Purge gas flow)
Exh Pressure… (Exhaust Pressure Sensor)
DP Clean…
Auxiliary gauge… Choice of Voltage/Strain Gauge/Pirani Gauge
PT100 1…
PT100 2…
Pressure…
Pressure 2…
Max pressure 1… xxxxmbar
Max Pressure 2… xxxxmbar
Gas Ballast... (Additional gas ballast for GXS450 and GXS750 systems
fitted with the medium duty gas module only)
