5
SERIAL COMMUNICATION PROTOCOL
Example:
Pump operation mode : 01
hex
= 1 = Levitation
WARNING being detected : 000C
hex
= 0004
hex
OR 0080
hex
=
"WARNING: First Damage Limit" and
"WARNING: Imbalance X_H"
The number of error : 02
hex
= 2 errors
Error 1 : 0D
hex
= 13 = Disturbance Xh
Error 2 : 0F
hex
= 15 = Disturbance Xb
Error 3 to 79 : 00
hex
= No error detected
Parameter 1 2 3 4 5 6 7 8 9 10
ASCII
0 1 0 0 0 C 0 2 0 D 0 F 0 0 0 0 0 0 0 0 0 0
HEX
30 31 30 30 30 43 30 32 30 44 30 46 30 30 30 30 30 30 30 30 30 30
Parameter 11 12 13 14 15
[Omitted]
70 71 72 73 74
ASCII
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
HEX
30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
Parameter 75 76 77 78 79 80 81 82
ASCII
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
HEX
30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
