Edwards STP-iS2207 Series User Manual

STP-iS2207 Series Turbomolecular Pump
MT-89E-001-C
Page 111
5
SERIAL COMMUNICATION PROTOCOL
5.4.16 ReadOptionFunc
Function: Reads the setting value of the input operation port, warning function, and serial
communication time out.
Transmission frame:
*1
PC→SIM
Stx 0 0 1 ? = Etx LRC
SIM→PC
Ack
PC→SIM
*1
Ack
SIM→PC
Stx 0 0 1 Sp = Parameter 1 to 13 Etx LRC
*1 The HEX code of ASCII character ' = ' is "3D".
Parameter Item Data format Remarks
1 Input operation port setting 8-bits hexadecimal
coded ASCII
2
*1
TMS Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
3 [System reservation] 48-bits hexadecimal
coded ASCII
4 Second Damage Limit Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
5 First Damage Limit Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
6
Pump Runtime Over Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
7
Pump Runtime Over Warning
Hours setting (×100 hours)
32-bits hexadecimal
coded ASCII
8 Imbalance Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
9
Pump Overload Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
10
Pump Overload Warning
Motor current setting
16-bits hexadecimal
coded ASCII
0.1 % step
11
Pump Overload Warning
Rotational speed setting
16-bits hexadecimal
coded ASCII
0.1 % step
*1 Valid only with TMS specification
