INSTALLATION
3
3.1.2 Installation area
Leave enough space for the followings in addition to that for the STP pump: (see Figure 10)
Space for maintenance and inspection.
Space for connecting cables.
CAUTION
DO NOT bend the power cable excessively and beware of any obstacles when installing the STP
pump. In addition, leave enough space to install other cables without bending them excessively.
Side view
Figure 10 - Space around the STP pump
