Edwards STP-iS2207 Series User Manual

STP-iS2207 Series Turbomolecular Pump
MT-89E-001-C
Page 127
6
STP-LINK AND DISPLAY UNIT
6 STP-LINK and DISPLAY UNIT
The STP-Link (optional accessory) and the display unit iDT-001 (optional accessory) are available with
the STP pump.
CAUTION
The connector of the STP-Link (optional accessory) and the display unit iDT-001 (optional
accessory) are not waterproof and dust-proof. The "STP-LINK" connector (X5) of the STP pump is
waterproof and dust-proof when the cover is attached. When the STP-Link and display unit iDT-001
are connected, the waterproof and dust-proof state of the pump cannot be maintained. DO NOT
leave the STP-Link and display unit iDT-001 constantly connected to the pump in an environment
affected by dust and water splashes. There is a risk that the STP pump may fail.
6.1 STP-Link
The "STP-Link" is a Windows application for operating the STP pump, confirming the pump status or
setting various settings. Table 32 shows the principal functions.
See the Instruction Manual of the "STP-Link" for the detailed specification and operating method.
Item Functions
Operating function Start, stop and failure reset operation of STP pump
Confirmation function Operational state of STP pump
Software version
Serial number
STP pump model
Operation hours
Number of starts
Bearing damage integrated value
Error history
Option setting function Remote operation mode setting
Serial port setting
Rotational speed setting
TMS function setting
*1
Warning function setting
*1 Valid only with TMS function
Table 32 - Functions of STP-Link
