Edwards STP-iS2207 Series User Manual

STP-iS2207 Series Turbomolecular Pump
MT-89E-001-C
Page 14
TECHNICAL DATA
PAG
E
14
2
2.4 Control unit
The values shown below are typical. They are not guaranteed.
Item STP-iS2207 / STP-iS2207C
Input voltage ACV 200 to 240
Input power VA 750 maximum
Input frequency Hz 50/60 ± 2
Leakage current mA 2.0 maximum
Input phase Single phase
Main fuse specification A 6.3
Current Ampere Interrupting Capacity
(AIC)
A
100
(250V AC 50/60 Hz)
Pollution degree 2
Installation category
Ⅱ
Motor driving system 3-phase d.c. brushless motor driver
Output frequency under normal operation Hz 608 maximum
Panel indication LED POWER (Green LED)
FAILURE (Red/Orange LED)
ROTATION (Green/Orange LED)
Data (Green LED)
Off-Line (Orange LED)
Error (Red LED)
Input/Output connector AC POWER X1 (3 pins)
REMOTE X2 (25 pins)
COM1 X3 (9 pins)
STP-LINK X5 (8 pins)
