Edwards STP-iS2207 Series User Manual

STP-iS2207 Series Turbomolecular Pump
MT-89E-001-C
Page 117
5
SERIAL COMMUNICATION PROTOCOL
Example:
1. Pump model:
5354502D69533232303720202020202020202020hex
= STP-iS2207
2. Damage point: 32
hex
= 50
Parameter 1
"S" "T" "P" "–" "i" "S" "2" "2" "0" "7"
ASCII
5 3 5 4 5 0 2 D 6 9 5 3 3 2 3 2 3 0 3 7
HEX
35 33 35 34 35 30 32 44 36 39 35 33 35 32 33 32 33 30 33 37
Parameter 1
" " " " " " " " " " " " " " " " " " " "
ASCII
2 0 2 0 2 0 2 0 2 0 2 0 2 0 2 0 2 0 2 0
HEX
32 30 32 30 32 32 32 30 32 30 32 30 32 30 32 30 32 30 32 30
Parameter 2 3 4
ASCII
*1 *1 *1 *1 *1 *1 *1 *1
0 0 3 2
*1 *1 *1 *1 *1 *1 *1 *1
HEX
30 30 33 32
Parameter 4
ASCII
*1 *1 *1 *1 *1 *1 *1 *1
HEX
*1 System reservation
