EFI Pro 24f - Rear Carriage Assembly

Document ID: OMM-00148 Rev. B
17
Rear Carriage Assembly
The Rear of the Carriage Assembly contains the following items:
1
2
3
Figure 3-4: Carriage Rear View (No Covers Shown)
1Print Head Control Board 2Voltage Control Board 3Overflow Tanks
