3.1.2 EFI Pro 24f UV Lamps
The EFI Pro 24f is equipped with UV Lamps which provide a superior technology for ink curing.
1
2
3
5
4
6
Figure 3-5: LED Lamp Detail (Right Lamp Shown)
1Lamp Interface Board Housing2Lamp Mounting Bracket Assembly 3 Anti-static Bar Assembly
4Fans & Filter Assemblies 5Electrical/Communications
Connection Point
6Carriage Safety Stop Assembly
