3.4.3 Energy Chain
The Energy Chain (E-Chain) is attached to the back side of the carriage and moves with the carriage when it is in motion during printing
operations. The E-Chain continuously supplies the moving carriage with the following:
1
2
3
4
• White Ink
• CMYK Ink
• Electrical Power
• Positive and Negative Pressure
• Communication Signals
• Printing Data
Figure 3-15: Energy Chain (E-Chain)
1E
-Chain
2Internal Tubes and Wiring
3E-Chain Trough Cover
4E-Chain Trough
