EFI Pro 24f - Sample Images

Document ID: OMM-00148 Rev. B
69
6.4.1 Sample Images
Note that the following images include one with a white fill background and one with true blank space (represented by check
boxes) that runs the full width of the image.
Figure 6-14: Image With White Field/White Fill
Figure 6-15Image With Blank Space/White Space
1Rows of Blank Space Running
the Width of the Image(s)
2Checked Background
Represents True Blank
Space in Image
2
1
1
1
1
1
1
1
1
1
