3.3 Operator Station Components
The Pro 24f operator’s computer components are attached to the printer’s computer compartment. Those components are:
1. A 22” flat-panel display a full-size keyboard, and a two-button wheel-mouse (Not Shown).
2. The Keyboard Tray is used to support the keyboard and mouse used for
printer operation.
1
2
3
Figure 3-8: Operator Station
Note: CPU is provid
ed by end user.
1Monitor
2Keyboard Tray
3CPU Cover
