EFI Pro 24f - Offset Tab

Document ID: OMM-00148 Rev. B
49
Offset Tab
The Offset tab is generally used only by Field Service Engineers
and contains the following items:
1. Determines the type of calibration to be executed. Each selection
shows different values below.
2. Displays Print Head X Alignment Values.
3. Displays print head R offset values.
4. OK to save or Cancel to exit.
Note: This tab is used only by Field Service Engineers.
1
2
3
4
Figure 4-22Parameters Offset Tab
