Document ID: OMM-00148 Rev. B
66
6.3 Print Workflows
The EFI Pro 24f printer has many different resolutions and options for creating bco files for printing at different speeds and
output qualities. With experience the selection of these options will become clearer. When selecting a work flow for file
preparation in the Fiery XF software, be aware that different options result in different printer output speeds and can have
different output qualities as well.
The charts below contain several work flows that EFI has found useful in day to day operation of the EFI Pro 24f printers.
Note: Different printer modes have different intended viewing distances for the printed output. In general, the faster
output speeds are intended to be used in creating prints that are viewed from larger distances.
Standard Workflows
Output Mode Up to Sq. Ft (Sq.m)/Hr. Printer Settings
Express 976 (91) CMYK | 300x600 | 1 pass
Distant View/Outdoor 569 (53) CMYK | 600x600 | 2 pass
Production 311 (29) CMYK | 600x600 | 4 pass
POP Quality 178 (17) CMYK | 600x600 | 8 pass
High Quality 119 (11) CMYK | 900x600 | 12 pass
Ultra Quality 60 (6) CMYK | 1200x600 | 24 pass
