5.3 Set Media Vacuum Chamber Controls
Open the vacuum valves for the desired chambers. Use vacuum only for chambers covered by the media and close vacuum valves for all
other chambers.
1
2
3
4
Figure 5-2: Platen Vacuum Control Knob Layout
Figure 5-3
1V
alve 1 2Valve 2
3Valve 3 4Valve 4
