4.3.1 Carriage Controls
The Carriage controls perform the following functions:
1. Moves carriage up on the Z-Axis to the upper limit.
2. Moves carriage down on the Z-Axis to the lower limit.
3. Selectable carriage height settings.
4. Allows the carriage to automatically set the Gap.
5. Sets the carriage gap measurement positive distance from the Media Positive Value.
6. Sets Measurement Position.
Figure 4-12: Carriage Controls
1Carriage UP 2Carriage DOWN 3 Click to Set Print Gap
4Gap Setting 5Auto Gap Detect 6 Sets Measurement Position
1
2
4
5
3
6
