Document ID: OMM-00148 Rev. B
43
4.3.3 Lamp Controls
The Lamp Controls provide the following functions:
Figure 4-14: X-Y Lamp Controls
Note: Normally all 4 bulbs should be turned on in order to optimize curing in both directions.
1Left Lamp Control (ON/OFF) 2 Right Lamp Control (ON/OFF)
3Indicates LED Lamp is curing from left to right4Indicates LED Lamp is curing from right to left
