3.4 Printer Rear Components
This section illustrates the major components located on the rear of the printer.
Figure 3-13: Printer Rear (Feed Side)
Caution! Keep all safety interlocks, covers, and guards in place and functional. Never operate printer with covers, doors, or
guards removed or with malfunctioning interlocks.
* Field Service ONLY
1IGUS track
2Ink Cabinet
3Access to Power Supplies and Relays*
4Access to Vacuum Motor Compartment
5
MainBeam(CarriageBeam)
6Energy chain
To Next Page
