Electrolux T4900 - Page 81

81
Drum with bearing
Service
manual
IMGT4CR16
Remountdrumandbearing
 • Remountintheoppositeorder.
 • Placedrumcarefully.UseAntifretpasteor
similarqualitytolubricatethebearingsurface.
  NOTE!
After mounting the drum tighten the
4 nuts (O) in the bearing disc using 40 Nm.
 • Mountwedge(M).
 • Fastenthe2tailstockscrews(Q)intheouter
ringusingOmnitSeal40Nmorsimilar
qualityandtightenthemusing16Nm.
 • Mountpulleywithclampingsleeve.
 • Tightenthe2screws(K)using90Nm.
 • MountV-belts(J).
  Tightenthebelt,seeunderheading
"Tighteningbelt"inchapter"Periodic
maintenance".
6
7
8
9
6
7
8
9
J
